RealSea’s QSFP28-100G-LR4 optical transceivers are based on 100G Ethernet IEEE 802.3ba standard. The QSFP28 transceiver converts 4 inputs channels of 25Gb/s electrical data to 4 LAN-WDM optical signals, and multiplexes them into a single channel for 100Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 100Gb/s input into 4 LAN-WDM channels signals, and converts them to 4 channel output electrical data.
Download
Share:
4x25G LAN-WDM optical architecture up to 103.1Gbps
Up to 10km transmission
Duplex LC connector
Power dissipation < 3.5W
Built-in digital diagnostic functions
Operating temperature range: 0◦C to 70◦C
Compliant with IEEE 802.3bm
Compliant with QSFP28 MSA
Compliant with SFF-8665, SFF-8636
Compliant with RoHS
General Specifications
Parameter | Symbol | Min | Typ | Max | Unit |
Data Rate | DR | 100 | Gb/s | ||
Bit Error Rate | BER | 10−12 | |||
| Operating Temperature | Tc | 0 | 70 | ◦C | |
Storage Temperature | TSTO | -40 | 85 | ◦C | |
| Input Voltage | Vcc | 3.14 | 3.30 | 3.46 | V |
| Maximum Voltage | VMAX | -0.5 | 4 | V |
| Product attributes | |||
Brand | Realsea Technology | RX Sensitivity : | < -8.4dBm |
Part Number | QSFP28-100G-LR4 | Power dissipation : | ≤3.5w |
Data Rate | 100 Gbps | DDM/DOM : | Supported |
Connector Type | QSFP28 | EMC : | Supported |
Wavelength : | LWDM4 | Commercial Temperature : | 0 to 70°C (32 to 158°F) |
Transmission Distance : | 10KM | MTBF : | 1,000,000 Hours |
Connector : | LC | Receiver Overload : | 4dBm |
TX output Power : | -0.5~4dBm | Extinction Ratio : | >4.5dB |
Transmitter Type : | DML | Warranty : | 3 year |
RX Type : | 4 x PIN ROSA | ||
