Optical module
Operating data rate support 25.2Gbps to 28.1Gbps
Hot-pluggable SFP+ footprint
850nm VCSEL laser transmitter and PIN receiver
Built-in digital diagnostic functions
Up to 100m in length
Low power consumption (module working power <0.5W@Single-end)
Compliant with IEEE 802.3
Compliant with FC-PI-6
Compliant with SFF-8402
Compliant with SFF-8419
Compliant with SFF-8432
Compliant with SFF-8472
RoHS6 Compliant
General Specifications
Parameter | Symbol | Min | Typ | Max | Unit |
Data Rate | DR | 10 | Gb/s | ||
Bit Error Rate | BER | 5X10−5 | |||
Operating Temperature | TC | 0 | 70 | ◦C | |
Storage Temperature | TSTO | -40 | 85 | ◦C | |
Input Voltage | Vcc | 3.14 | 3.30 | 3.46 | V |
| Maximum Voltage | VMAX | -0.5 | 4 | V | |
| Supply Current | Icc | 180 | 290 | mA | |
| Product Weight | G | 54.0 | g/PCS | ||
| Fiber Optical Cable Weight | G | 7.5 | g/M |
| Product attributes | |
Brand | Realsea Technology |
Part Number | SFP-25G-AOC*M |
Data Rate | 25Gbps |
Connector Type | SFP+ to SFP+ |
Cable Length | 1~150m |
Cable Type | OM4 |
Minimum Bend Radius | 7.5mm |
Power Consumption | <0.5W |
Jacket Material | PVC (OFNR) |
Commercial Temperature | 0 to 70°C (32 to 158°F) |
Warranty | 3 year |
